Cryogenic air separation units are designed for production of oxygen, nitrogen and argon, as well as rare gases: neon, xenon, krypton, helium.
Cryogenic air separation units are widely used in various fields of activity. The scope of their application covers such sectors of industry as:
The principle of operation is based on air separation by means of low temperature rectification. This method is based on the boiling temperature difference for the air components and on the difference of the contents of the balanced liquid and steam mixtures.
The units are constructed on the basis of effective production cycles, which not only ensure high energy efficiency of the equipment, but also allow to implement different operating modes within one and the same installation, as well as to perform high-range modes control. Thus, the units can be adapted to a particular industrial environment, taking into account its features and Customer’s requirements.
Advantages of cryogenic air separation units:
Air separation plants are supplied as complete systems, including peripheral equipment, in particular, a complete set of gas analyzers, including a CO2 analyzer, as a mandatory and integral element of the safety loop. And also external filters and silencers.
In accordance with the requirements of a number of industries for continuity and reliability of the cycle, major components of the installation (cleaning unit heater, turbo- expander/compressor) are reserved. Backup equipment is included in the scope of supply and is installed in the plant along with the main equipment.
|Capacity||70 000 nm³/h (oxygen); 20 000 nm³/h (nitrogen); up to 2 500 nm³/h (argon)|
|Purity||99.6 % (oxygen), from 95 to 99.999 % (nitrogen, argon)|
|Pressure||in accordance with Customer’s requirements|
